Microsoft’s cyberphysical system researchers recently identified multiple high-severity vulnerabilities in the CODESYS V3 software development kit (SDK), a software development environment widely used to program and engineer programmable logic controllers (PLCs). Exploitation of the discovered vulnerabilities, which affect all versions of CODESYS V3 prior to version 3.5.19.0, could put operational technology (OT) infrastructure at risk of attacks, such as remote code execution (RCE) and denial of service (DoS). The discovery of these vulnerabilities highlights the critical importance of ensuring the security of industrial control systems and underscores the need for continuous monitoring and protection of these environments.
CODESYS is compatible with approximately 1,000 different device types from over 500 manufacturers and several million devices that use the solution to implement the international industrial standard IEC (International Electrotechnical Commission) 611131-3. A DoS attack against a device using a vulnerable version of CODESYS could enable threat actors to shut down a power plant, while remote code execution could create a backdoor for devices and let attackers tamper with operations, cause a PLC to run in an unusual way, or steal critical information. Exploiting the discovered vulnerabilities, however, requires user authentication, as well as deep knowledge of the proprietary protocol of CODESYS V3 and the structure of the different services that the protocol uses.
Microsoft researchers reported the discovery to CODESYS in September 2022 and worked closely with CODESYS to ensure that the vulnerabilities are patched. Information on the patch released by CODESYS to address these vulnerabilities can be found here: Security update for CODESYS Control V3. We strongly urge CODESYS users to apply these security updates as soon as possible. We also thank CODESYS for their collaboration and recognizing the urgency in addressing these vulnerabilities.
Below is a list of the discovered vulnerabilities discussed in this blog:
| CVE | CODESYS component | CVSS score | Impact |
| CVE-2022-47379 | CMPapp | 8.8 | DoS, RCE |
| CVE-2022-47380 | CMPapp | 8.8 | |
| CVE-2022-47381 | CMPapp | 8.8 | |
| CVE-2022-47382 | CmpTraceMgr | 8.8 | |
| CVE-2022-47383 | CmpTraceMgr | 8.8 | |
| CVE-2022-47384 | CmpTraceMgr | 8.8 | |
| CVE-2022-47385 | CmpAppForce | 8.8 | |
| CVE-2022-47386 | CmpTraceMgr | 8.8 | |
| CVE-2022-47387 | CmpTraceMgr | 8.8 | |
| CVE-2022-47388 | CmpTraceMgr | 8.8 | |
| CVE-2022-47389 | CMPTraceMgr | 8.8 | |
| CVE-2022-47390 | CMPTraceMgr | 8.8 | |
| CVE-2022-47391 | CMPDevice | 7.5 | DoS |
| CVE-2022-47392 | CmpApp/ CmpAppBP/ CmpAppForce | 8.8 | |
| CVE-2022-47393 | CmpFiletransfer | 8.8 |
In this blog, we provide an overview of the CODESYS V3 protocol structure, highlighting several key components, and describe the main issue that led to our discovery of the vulnerabilities. The full research and the results can be found in our report on Github. We also provide an open-source forensics tool to help users identify impacted devices, security recommendations for those affected, and detection information for potentially related threats.
CODESYS is a software development environment that provides automation specialists with tools for developing automated solutions. CODESYS is a platform-independent solution that helps device manufacturers implement the international industrial standard IEC 611131-3. The SDK also has management software that runs on Windows machines and a simulator for testing environments, allowing users to test their PLC systems before deployment. The proprietary protocols used by CODESYS use either UDP or TCP for communication between the management software and PLC.
CODESYS is widely used and can be found in several industries, including factory automation, energy automation, and process automation, among others.
The vulnerabilities were uncovered by Microsoft researchers while examining the security of the CODESYS V3 proprietary protocol as part of our goal to improve the security standards and create forensic tools for OT devices. During this research, we examined the structure and security of the protocol that is used by many types and vendors of PLCs. We examined the following two PLCs that use CODESYS V3 from different vendors: Schneider Electric Modicon TM251 and WAGO PFC200.
The CODESYS network protocol works over either TCP or UDP:
The CODESYS network protocol consists of four layers:
| Component name | Component ID |
| CmpApp | 0x2 |
| CmpAlarmManager | 0x18 |
| CmpAppBP | 0x12 |
| CmpAppForce | 0x13 |
| CmpCodeMeter | 0x1D |
These components use the Tags layer for data transmission and encoding, which is transmitted over the Services layer.
There are two types of tags: parent and data. Both tags have identical structure but different sizes and purposes. The following table provides the basic structure of tags:
| Field | Parent tag size (in bytes) | Data tag size (in bytes) | Description |
| Tag ID | 2 | 1 | The tag ID. The value of the most significant bit determines the type of tag. For parent tag, the value of the most significant bit is set. |
| Tag size | 2 | 1 | The size of the data. |
| Tag data | (Tag size) | (Tag size) | The data of the tag. |
Tags can represent any type of data, and it is extracted by the component. The difference between a parent tag and a data tag is that a parent tag is used for linking several tags into one logical element.
Tags contain several important structures, including BTagReader and BTagWriter, which include the following fields:
These structures are allocated for each request and exist only in the context of the request. Each request handler creates BTagWriter and BTagReader tags and uses them to parse and handle requests. Tag IDs are not unique across services, meaning each service may have its own definition for a tag ID. Tag IDs are handled in the context of each service.
The following figure provides an example of a Tag layer and relevant fields.
This example contains the following tags:
CODESYS consists of components and each component is responsible for a portion of functionality of the PLC. The following is a list of example components:
Each component includes a number of services that the client can ask to use. For example, CMPTraceMgrincludes the following:
Each service is identified by a unique number for the specific component.
A security issue was discovered inside the tag decoding mechanism that led to multiple vulnerabilities that could put devices at risk of attacks such as RCE and DoS.
In order to understand the security issue, let’s analyze the service TraceMgrRecordAdd of the component CMPTraceMgr by examining the code that activates the relevant service.
The TraceMgrRecordAddByTag appears to correspond to TraceMgrRecordAdd.
As displayed in Figure 5, the following code initializes structure from tags that are sent to the service.
The following figure looks at the code for the TraceMgrAddNewRecordPartByTag method, which copies data from different tags into an output buffer.
The whole tag is copied into the buffer without validating the size, causing buffer overflow.
Fifteen places in CODESYS V3 SDK were found with the same issue in different components that could lead to remote attackers gaining full control over the device.
We were able to apply 12 of the buffer overflow vulnerabilities to gain RCE of PLCs. Exploiting the vulnerabilities requires user authentication as well as bypassing the Data Execution Prevention (DEP) and Address Space Layout Randomization (ASLR) used by both the PLCs. To overcome the user authentication, we used a known vulnerability, CVE-2019-9013, which allows us to perform a replay attack against the PLC using the unsecured username and password’s hash that were sent during the sign-in process, allowing us to bypass the user authentication process.
IEC tasks are the execution unit of CODESYS runtime. It is the equivalent to thread in operating systems. A single component can have more than one task and will have at least one IEC task. The tasks are managed by CODESYS runtime.
Each IEC task has a memory segment with read, write, and execute permissions. If a threat actor writes code there, it could be run without the data execution prevention mitigation being applied.
The IEC task segment is also where the stack is defined, meaning we don’t need to handle DEP.
Since the IEC tasks are part of the CODESYS code, they are present on all PLCs of all vendors that utilize CODESYS.
By looking for gadgets, we can bypass the ASLR. In the examples below, we can see part of the gadgets that we used in our exploit.
The complete exploit steps:
We were able to exploit the two PLCs that we researched.
Demo video:
With CODESYS being used by many vendors, one vulnerability may affect many sectors, device types, and verticals, let alone multiple vulnerabilities. All the vulnerabilities can lead to DoS and 1 RCE. While exploiting the discovered vulnerabilities requires deep knowledge of the proprietary protocol of CODESYS V3 as well as user authentication (and additional permissions are required for an account to have control of the PLC), a successful attack has the potential to inflict great damage on targets. Threat actors could launch a DoS attack against a device using a vulnerable version of CODESYS to shut down industrial operations or exploit the RCE vulnerabilities to deploy a backdoor to steal sensitive data, tamper with operations, or force a PLC to operate in a dangerous way.
CODESYS V3 versions prior to 3.5.19.0 are vulnerable to the discovered vulnerabilities. It is recommended to first identify the devices using CODESYS in your network and check with device manufacturers to determine which version of the CODESYS SDK is used and whether a patch is available. It is also recommended to update the device firmware to version to 3.5.19.0 or above.
General recommendations:
To assist with identifying impacted devices, the cyberphysical systems research team has released an open-source software tool on GitHub that allows users to communicate with devices in their environment that run CODESYS and extract the version of CODESYS on their devices in a safe manner to confirm if their devices are vulnerable. In addition, the cyberphysical system research team also released a tool for performing a forensics investigation on CODESYS V3 devices as part of its arsenal of open-source tools available on GitHub.
